Fold both pedals by placing your thumb on the pedal arm (crank) and fingers on the pedal. Then squeeze and pull the pedal up.
Spin the nearest pedal to the top
Twist the handlebars towards you
Step on the rear lever (behind the pedals) and lift the saddle by an inch to release the rear wheel
Then lift the handlebars and saddle to swing the rear wheel underneath the bike in a single movement. Rest the rear of the bike on the ground.
Undo the lower hinge (above the front wheel), (five full turns will do)
Holding the saddle and handlebars, lift the bike slightly until the front wheel starts to come towards you. Guide it into place with your right foot, so that it’s parallel to the top tube.
To secure the fold, lean the bike towards you and roll forwards slightly on the front wheel, until the loop (on the front wheel) and retaining hook are aligned. Rest the bike back on the ground, so that the hook passes through the loop.
Undo the top hinge (at the front of the bike) (five full turns will do) and lower the handlebars
To complete the fold, undo the seat post quick release and lower the saddle.
Stabilising the folded bike
1. Make sure that the bike is resting on its feet, not the seat post or pedals when folded.
2. On a train, rest the non-drive side against the train rack / train wall
